Features
- Complete Energy Storage Solution Featuring One Anker SOLIX F3800 Plus And Six BP3800 Expansion Batteries
- Massive 26.88kWh Total Battery Capacity For Extended Backup Runtime
- 6000-Watt Continuous Pure Sine Wave Output Powers Essential And High-Demand Appliances
- Supports 120V And 240V Devices Including HVAC Systems, Water Pumps, And Workshop Equipment
- Expandable Home Backup System Designed For Energy Independence
- Advanced LiFePO4 Battery Technology Delivers 3,000+ Charge Cycles
- Dual MPPT Solar Controllers Accept Up To 3200W Of Solar Charging Power
- Generator Bypass Charging Supports Up To 6000W Input For Rapid Recharging
- Integrated Battery Management System Provides Advanced Safety Protection
- Compatible With Anker Smart Home Power Kit For Whole-Home Integration
- Built-In Wi-Fi And Bluetooth Connectivity For Remote Monitoring
- Real-Time Energy Tracking And Configuration Through The Anker Mobile App
- RV Ready With Dedicated TT-30 Outlet And NEMA 14-50 Output
- Designed For Home Backup, Emergency Preparedness, Off-Grid Living, And Mobile Applications
- Backed By Anker's Industry-Leading Warranty And Support Network
Specifications
| Total Battery Capacity | 26,880Wh (26.88kWh) |
| Base Unit Capacity | 3,840Wh |
| Expansion Battery Capacity | 6 × 3,840Wh |
| Battery Chemistry | LiFePO4 (LFP) |
| Cycle Life | 3,000+ Cycles |
| AC Output Power | 6,000W Continuous |
| Peak Surge Output | 9,000W |
| Output Voltage | 120V / 240V |
| Solar Input Power | 3,200W Maximum |
| MPPT Controllers | Dual 1,600W MPPT |
| Solar Voltage Range | 11V–165V |
| Generator Charging | Up To 6,000W |
| Connectivity | Wi-Fi & Bluetooth |
| Dimensions (F3800 Plus) | 27.6 x 15.3 x 15.6 in. |
| Weight (F3800 Plus) | 136.7 lbs |
| Total System Weight | 573.5 lbs |
Installation
- Place The F3800 Plus On A Stable, Dry Surface With Proper Ventilation
- Arrange The Six BP3800 Expansion Batteries Near The Main Unit For Efficient Cable Routing
- Connect Each Expansion Battery Using Official Anker Expansion Battery Cables
- Verify All Batteries Are Recognized Through The LCD Display Or Anker App
- Connect Compatible Solar Panels To The Dual MPPT Inputs Within The Allowed Voltage Range
- Configure Energy Settings And Monitoring Through Wi-Fi Or Bluetooth Connectivity
- For Whole-Home Backup Applications, Install With The Anker Smart Home Power Kit Or Approved Transfer Switch
- Inspect All Electrical Connections And Confirm Proper Grounding Before Startup
- Follow Manufacturer Guidelines And Local Electrical Codes During Installation
